IKD03N60RF
lmages are for reference only.IKD03N60RF
IGBT 600V 5A 53.6W TO252-3
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
51,664 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT Trench 600 V 5 A 53.6 W Surface Mount PG-TO252-3
IKD03N60RF
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Infineon Technologies |
| Series | TrenchStop® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| IGBT Type | Trench |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 5 A |
| Current - Collector Pulsed (Icm) | 7.5 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 2.5A |
| Power - Max | 53.6 W |
| Switching Energy | 90µJ |
| Input Type | Standard |
| Gate Charge | 17.1 nC |
| Td (on/off) @ 25°C | 10ns/128ns |
| Test Condition | 400V, 2.5A, 68Ohm, 15V |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | PG-TO252-3 |
| Reverse Recovery Time (trr) | 31 ns |
| Base Product Number | IKD03N |
| Product Attribute |  |
 |
 |
 |
| Part Number | IKD03N60RFAATMA1 | IKD03N60RFATMA1 | IKD04N60R | IKD04N60RAATMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IGBT 600V 5A 53.6W TO252-3 | IGBT TRENCH/FS 600V 6.5A TO252-3 | IGBT TRENCH 600V 8A TO252-3 | IGBT TRENCH 600V 8A TO252-3 |
| Series | TrenchStop™ | TrenchStop™ | TrenchStop® | TrenchStop™ |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
