IGBT Trench Field Stop 600 V 80 A 306 W Through Hole PG-TO247-3-1
IKW40N60H3FKSA1
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Infineon Technologies |
| Series | TrenchStop® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 80 A |
| Current - Collector Pulsed (Icm) | 160 A |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 40A |
| Power - Max | 306 W |
| Switching Energy | 1.68mJ |
| Input Type | Standard |
| Gate Charge | 223 nC |
| Td (on/off) @ 25°C | 19ns/197ns |
| Test Condition | 400V, 40A, 7.9Ohm, 15V |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | PG-TO247-3-1 |
| Reverse Recovery Time (trr) | 124 ns |
| Base Product Number | IKW40N60 |
| Product Attribute |  |
 |
 |
 |
| Part Number | IKW40N120CH7XKSA1 | IKW40N120CS6XKSA1 | IKW40N120CS7XKSA1 | IKW40N120H3FKSA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT TRENCH FS 1200V 82A TO247-3 | IGBT TRENCH FS 1200V 80A TO247-3 | IGBT TRENCH FS 1200V 82A TO247-3 | IGBT TRENCH FS 1200V 80A TO247-3 |
| Series | TRENCHSTOP™ | TrenchStop™ | TRENCHSTOP™ | TrenchStop® |
| Packaging | Tube | Tube | Tube | Tube |
