IL 510-3E
lmages are for reference only.IL 510-3E
DGTL ISO 2500VRMS 1CH GP 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
86,744 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Digital Isolator 2500Vrms 1 Channel 2Mbps 30kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
IL 510-3E
| Category | Isolators - Digital Isolators - |
| Manufacturer | NVE Corp/Isolation Products |
| Series | IsoLoop® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Technology | GMR (Giant Magnetoresistive) |
| Type | General Purpose |
| Isolated Power | No |
| Number of Channels | 1 |
| Inputs - Side 1/Side 2 | 1/0 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 2500Vrms |
| Common Mode Transient Immunity (Min) | 30kV/µs |
| Data Rate | 2Mbps |
| Propagation Delay tpLH / tpHL (Max) | 25ns, 25ns |
| Pulse Width Distortion (Max) | 10ns |
| Rise / Fall Time (Typ) | 1ns, 1ns |
| Voltage - Supply | 3V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | IL 510 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |  |  |  |
| Part Number | IL 510-1E | IL 510-1ETR7 | IL 012-3E | IL 016E |
| Manufacturer | NVE Corp/Isolation Products | NVE Corp/Isolation Products | NVE Corp/Isolation Products | NVE Corp/Isolation Products |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGTL ISO 2500VRMS 1CH GP 8MSOP | DGTL ISO 2500VRMS 1CH GP 8MSOP | DGTL ISO 2500VRMS 2CH GP 8SOIC | DGTL ISO 2500VRMS 4CH GP 16SOIC |
| Series | IsoLoop® | IL500 | IsoLoop®, IL01x | IsoLoop®, IL01x |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube |
