IL4116-X007T
lmages are for reference only.IL4116-X007T
OPTOISOLATOR 5.3KV TRIAC
Datasheet6-SMD
92,210 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Triac Output 5300Vrms 1 Channel
IL4116-X007T
| Category | Isolators - Optoisolators - Triac-SCR Output Optoisolators |
| Manufacturer | Vishay Semiconductor Opto Division |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Output Type | Triac |
| Zero Crossing Circuit | Yes |
| Number of Channels | 1 |
| Voltage - Isolation | 5300Vrms |
| Voltage - Off State | 600 V |
| Static dV/dt (Min) | 10kV/µs |
| Current - LED Trigger (Ift) (Max) | 1.3mA |
| Current - Hold (Ih) | 200µA |
| Turn On Time | 35µs |
| Voltage - Forward (Vf) (Typ) | 1.3V |
| Current - DC Forward (If) (Max) | 60 mA |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD |
| Supplier Device Package | - |
| Approval Agency | BSI, CSA, cUR, FIMKO, UR |
| Base Product Number | IL4116 |
| Current - On State (It (RMS)) (Max) | 300 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | IL4116-X007 | IL4116-X009 | IL4116-X009T | IL4116-X019T |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISOLATOR 5.3KV TRIAC | OPTOISOLATOR 5.3KV TRIAC | OPTOISOLATOR 5.3KV TRIAC | OPTOISOLATOR 5.3KV TRIAC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tape & Reel (TR) |
