IMM0505S05
Manufacturer
XP PowerDescription
DC DC CONVERTER 5V 5W
Datasheet
DatasheetPackage
9-SIP Module, 5 Leads
In Stock
70,157 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IMM0505S05
IMM0505S05
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 5V 1A 4.5V - 9V Input
Quick Inquiry
IMM0505S05
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | XP Power |
| Series | IMM05 (5W) |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 9V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1A |
| Power (Watts) | 5 W |
| Applications | Medical |
| Features | Remote On/Off, OCP, SCP |
| Operating Temperature | -20°C ~ 100°C (With Derating) |
| Efficiency | 82% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 9-SIP Module, 5 Leads |
| Size / Dimension | 1.02" L x 0.36" W x 0.49" H (26.0mm x 9.3mm x 12.5mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | CB, CSA, TUV, UL |
| Standard Number | - |
| Base Product Number | IMM0505 |
| Voltage - Isolation | 1.5 kV |
