IPB010N06NATMA1
lmages are for reference only.IPB010N06NATMA1
MOSFET N-CH 60V 45A/180A TO263-7
DatasheetTO-263-7, D2PAK (6 Leads + Tab)
21,215 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 60 V 45A (Ta), 180A (Tc) 300W (Tc) Surface Mount PG-TO263-7
IPB010N06NATMA1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 45A (Ta), 180A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Rds On (Max) @ Id, Vgs | 1mOhm @ 100A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 280µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 15000 pF @ 30 V |
| FET Feature | - |
| Power Dissipation (Max) | 300W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TO263-7 |
| Package / Case | TO-263-7, D2PAK (6 Leads + Tab) |
| Base Product Number | IPB010 |
| Gate Charge (Qg) (Max) @ Vgs | 208 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | IPB011N04LGATMA1 | IPB011N04NF2SATMA1 | IPB011N04NGATMA1 | IPB012N04NF2SATMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 40V 180A TO263-7 | TRENCH <= 40V | MOSFET N-CH 40V 180A TO263-7 | TRENCH <= 40V |
| Series | OptiMOS™ | StrongIRFET™2 | OptiMOS™ | StrongIRFET™2 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
