IPC100N04S402ATMA1
lmages are for reference only.IPC100N04S402ATMA1
MOSFET N-CH 40V 100A 8TDSON
Datasheet8-PowerTDFN
79,354 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 40 V 100A (Tc) 150W (Tc) Surface Mount PG-TDSON-8-23
IPC100N04S402ATMA1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS™ |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 100A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 2.4mOhm @ 50A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 80µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 8100 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 150W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TDSON-8-23 |
| Package / Case | 8-PowerTDFN |
| Base Product Number | IPC100N |
| Gate Charge (Qg) (Max) @ Vgs | 105 nC @ 10 V |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
 |
| Part Number | IPC100N04S51R2ATMA1 | IPC100N04S51R7ATMA1 | IPC100N04S51R9ATMA1 | IPC100N04S52R8ATMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 40V 100A 8TDSON-34 | MOSFET N-CH 40V 100A 8TDSON-34 | MOSFET N-CH 40V 100A 8TDSON-34 | MOSFET N-CH 40V 100A 8TDSON-34 |
| Series | OptiMOS™ | OptiMOS™ | OptiMOS™ | OptiMOS™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
