IQS211B00000000DNR
lmages are for reference only.IQS211B00000000DNR
1 CH CAPACITIVE SENSOR WITH ACTI
Datasheet6-WDFN Exposed Pad
27,348 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Capacitive Touch Proximity Only 6-DFN (3x2.5)
IQS211B00000000DNR
| Category | Integrated Circuits (ICs) - Interface - Sensor-Capacitive Touch |
| Manufacturer | Azoteq (Pty) Ltd |
| Series | IQ Switch®, ProxFusion™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | |
| Type | Proximity Only |
| Proximity Detection | Yes |
| Number of Inputs | 1 |
| LED Driver Channels | Up to 1 |
| Interface | I2C |
| Resolution | - |
| Voltage - Supply | 1.8V ~ 3.6V |
| Current - Supply | 80mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-WDFN Exposed Pad |
| Supplier Device Package | 6-DFN (3x2.5) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | IQS211B00000000CSR | IQS211B00000000TSR | IQS211B00050000CSR | IQS211B00050000DNR |
| Manufacturer | Azoteq (Pty) Ltd | Azoteq (Pty) Ltd | Azoteq (Pty) Ltd | Azoteq (Pty) Ltd |
| RoHS Status | ||||
| Description | 1 CH CAPACITIVE SENSOR WITH ACTI | 1 CH CAPACITIVE SENSOR WITH ACTI | IQS211B00050000CSR | IQS211B00050000DNR |
| Series | IQ Switch®, ProxFusion™ | IQ Switch®, ProxFusion™ | IQ Switch®, ProxFusion™ | IQ Switch®, ProxFusion™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
