IQS7221E101QFR
Manufacturer
Azoteq (Pty) LtdDescription
IQS7221E101QFR
Datasheet
DatasheetPackage
20-UFQFN Exposed Pad
In Stock
70,018 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IQS7221E101QFR
IQS7221E101QFR
lmages are for reference only.Payment Methods
Delivery Services
Hall Effect Sensor Angle, Rotary External Magnet, Not Included SMD (SMT) Tab
Quick Inquiry
IQS7221E101QFR
Specifications
| Category | Sensors, Transducers - Position Sensors - Angle-Linear Position Measuring |
| Manufacturer | Azoteq (Pty) Ltd |
| Series | IQ Switch® ProxFusion® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| For Measuring | Angle, Rotary |
| Technology | Hall Effect |
| Rotation Angle - Electrical, Mechanical | 0° ~ 360° |
| Linear Range | - |
| Output | I2C, Quadrature |
| Output Signal | Clockwise Increase |
| Actuator Type | External Magnet, Not Included |
| Linearity | - |
| Resistance | 470 Ohms |
| Resistance Tolerance | - |
| Voltage - Supply | 2.2V ~ 3.5V |
| Mounting Type | Surface Mount |
| Termination Style | SMD (SMT) Tab |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 20-UFQFN Exposed Pad |
| Supplier Device Package | 20-QFN (3x3) |
| Grade | - |
| Qualification | - |
| Base Product Number | - |
