IR2233
lmages are for reference only.IR2233
IC GATE DRVR HALF-BRIDGE 28DIP
Datasheet28-DIP (0.600", 15.24mm)
74,274 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Inverting 28-PDIP
IR2233
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Driven Configuration | Half-Bridge |
| Channel Type | 3-Phase |
| Number of Drivers | 6 |
| Gate Type | IGBT, N-Channel MOSFET |
| Voltage - Supply | 10V ~ 20V |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| Current - Peak Output (Source, Sink) | 250mA, 500mA |
| Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | 1200 V |
| Rise / Fall Time (Typ) | 90ns, 40ns |
| Operating Temperature | 125°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 28-DIP (0.600", 15.24mm) |
| Supplier Device Package | 28-PDIP |
| Base Product Number | IR2233 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | IR2233J | IR2233JPBF | IR2233JPBF | IR2233JTR |
| Manufacturer | Infineon Technologies | Infineon Technologies | International Rectifier | Infineon Technologies |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant |
| Description | IC GATE DRVR HALF-BRIDGE 44PLCC | IC GATE DRVR HALF-BRIDGE 44PLCC | IR2233J - GATE DRIVER | IC GATE DRVR HALF-BRIDGE 44PLCC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Tape & Reel (TR) |
