IRF3703PBF
Manufacturer
International RectifierDescription
IRF3703 - 12V-300V N-CHANNEL POW
Datasheet
DatasheetPackage
TO-220-3
In Stock
42,402 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IRF3703PBF
IRF3703PBF
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 30 V 210A (Tc) 3.8W (Ta), 230W (Tc) Through Hole TO-220AB
Quick Inquiry
IRF3703PBF
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | International Rectifier |
| Series | HEXFET® |
| Packaging | Bulk |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 210A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 7V, 10V |
| Rds On (Max) @ Id, Vgs | 2.8mOhm @ 76A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 8250 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 3.8W (Ta), 230W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220AB |
| Package / Case | TO-220-3 |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 209 nC @ 10 V |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute | |
 |
 |
 |
| Part Number | IRF3703PBF | IRF3000 | IRF3000PBF | IRF3007PBF |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | |
| Description | MOSFET N-CH 30V 210A TO220AB | MOSFET N-CH 300V 1.6A 8SO | MOSFET N-CH 300V 1.6A 8SO | MOSFET N-CH 75V 75A TO220AB |
| Series | HEXFET® | HEXFET® | HEXFET® | HEXFET® |
| Packaging | Tube | Tube | Tube | Tube |
