IRF820ALPBF
lmages are for reference only.IRF820ALPBF
MOSFET N-CH 500V 2.5A I2PAK
DatasheetTO-262-3 Long Leads, I2PAK, TO-262AA
40,603 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 500 V 2.5A (Tc) 50W (Tc) Through Hole I2PAK
IRF820ALPBF
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 500 V |
| Current - Continuous Drain (Id) @ 25°C | 2.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 3Ohm @ 1.5A, 10V |
| Vgs(th) (Max) @ Id | 4.5V @ 250µA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 340 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 50W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | I2PAK |
| Package / Case | TO-262-3 Long Leads, I2PAK, TO-262AA |
| Base Product Number | IRF820 |
| Gate Charge (Qg) (Max) @ Vgs | 17 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | IRF820AL | IRF820 | IRF820 | IRF820 |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | STMicroelectronics | Harris Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | MOSFET N-CH 500V 2.5A I2PAK | MOSFET N-CH 500V 2.5A TO220AB | MOSFET N-CH 500V 4A TO220AB | 2.5A, 500V, 3.000 OHM, N-CHANNEL |
| Series | - | - | PowerMESH™ II | PowerMESH™ II |
| Packaging | Tube | Tube | Tube | Bulk |
