IRS26302DJPBF-IR
lmages are for reference only.IRS26302DJPBF-IR
HALF BRIDGE BASED IGBT/MOSFET DR
Datasheet44-LCC (J-Lead), 32 Leads
75,980 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Non-Inverting 44-PLCC, 32 Leads (16.51x16.51)
IRS26302DJPBF-IR
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | International Rectifier |
| Series | - |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| Driven Configuration | Half-Bridge |
| Channel Type | 3-Phase |
| Number of Drivers | 6 |
| Gate Type | IGBT, N-Channel MOSFET |
| Voltage - Supply | 10V ~ 20V |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| Current - Peak Output (Source, Sink) | 200mA, 350mA |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Rise / Fall Time (Typ) | 125ns, 50ns |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 44-LCC (J-Lead), 32 Leads |
| Supplier Device Package | 44-PLCC, 32 Leads (16.51x16.51) |
| Base Product Number | IRS26302 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | IRS26302DJPBF | IRS26302DJTRPBF | IRS26310DJTRPBF | IX6R11S3T/R |
| Manufacturer | Infineon Technologies | Infineon Technologies | International Rectifier | IXYS |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC GATE DRVR HALF-BRIDGE 44PLCC | IC GATE DRVR HALF-BRIDGE 44PLCC | HIGH VOLTAGE 3 PHASE GATE DRIVER | IC GATE DRVR HALF-BRIDGE 16SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR) |
