ISO7821FDWWR
lmages are for reference only.ISO7821FDWWR
DGTL ISO 5700VRMS 2CH GP 16SOIC
Datasheet16-SOIC (0.551", 14.00mm Width)
18,858 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Digital Isolator 5700Vrms 2 Channel 100Mbps 100kV/µs CMTI 16-SOIC (0.551", 14.00mm Width)
ISO7821FDWWR
| Category | Isolators - Digital Isolators - |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Capacitive Coupling |
| Type | General Purpose |
| Isolated Power | No |
| Number of Channels | 2 |
| Inputs - Side 1/Side 2 | 1/1 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 5700Vrms |
| Common Mode Transient Immunity (Min) | 100kV/µs |
| Data Rate | 100Mbps |
| Propagation Delay tpLH / tpHL (Max) | 16ns, 16ns |
| Pulse Width Distortion (Max) | 4.6ns |
| Rise / Fall Time (Typ) | 2.4ns, 2.4ns |
| Voltage - Supply | 2.25V ~ 5.5V |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.551", 14.00mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | ISO7821 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ISO7821FDW | ISO7821FDWR | ISO7821FDWW | ISO7820DW |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGTL ISO 5700VRMS 2CH GP 16SOIC | DGTL ISO 5700VRMS 2CH GP 16SOIC | DGTL ISO 5700VRMS 2CH GP 16SOIC | DGTL ISO 5700VRMS 2CH GP 16SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube |
