IXFT120N25X3HV
lmages are for reference only.IXFT120N25X3HV
MOSFET N-CH 250V 120A TO268HV
DatasheetTO-268-3, D3PAK (2 Leads + Tab), TO-268AA
78,176 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 250 V 120A (Tc) 520W (Tc) Surface Mount TO-268AA
IXFT120N25X3HV
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Littelfuse Inc. |
| Series | HiPerFET™, Ultra X3 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 250 V |
| Current - Continuous Drain (Id) @ 25°C | 120A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 12mOhm @ 60A, 10V |
| Vgs(th) (Max) @ Id | 4.5V @ 4mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 7870 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 520W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-268AA |
| Package / Case | TO-268-3, D3PAK (2 Leads + Tab), TO-268AA |
| Base Product Number | IXFT120 |
| Gate Charge (Qg) (Max) @ Vgs | 122 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | IXFT120N15P | IXFT120N30X3HV | IXFT100N30X3HV | IXFT10N100 |
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | IXYS |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 150V 120A TO268 | MOSFET N-CH 300V 120A TO268HV | MOSFET N-CH 300V 100A TO268HV | MOSFET N-CH 1000V 10A TO268 |
| Series | HiPerFET™, Polar | HiPerFET™, Ultra X3 | HiPerFET™, Ultra X3 | HiPerFET™ |
| Packaging | Tube | Tube | Tube | Tube |
