IXGR60N60C3D1
Manufacturer
IXYSDescription
IGBT 600V 75A 170W ISOPLUS247
Datasheet
DatasheetPackage
TO-247-3
In Stock
73,994 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IXGR60N60C3D1
IXGR60N60C3D1
lmages are for reference only.Payment Methods
Delivery Services
IGBT PT 600 V 75 A 170 W Through Hole ISOPLUS247™
Quick Inquiry
IXGR60N60C3D1
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | IXYS |
| Series | GenX3™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | PT |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 75 A |
| Current - Collector Pulsed (Icm) | 260 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 40A |
| Power - Max | 170 W |
| Switching Energy | 800µJ (on), 450µJ (off) |
| Input Type | Standard |
| Gate Charge | 115 nC |
| Td (on/off) @ 25°C | 21ns/70ns |
| Test Condition | 480V, 40A, 3Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | ISOPLUS247™ |
| Reverse Recovery Time (trr) | 25 ns |
| Base Product Number | IXGR60 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | IXGR60N60C2 | IXGR60N60C2D1 | IXGR60N60C3C1 | IXGR60N60B2 |
| Manufacturer | IXYS | IXYS | IXYS | IXYS |
| RoHS Status | ROHS3 Compliant | |||
| Description | IGBT 600V 75A 250W ISOPLUS247 | IGBT 600V 75A 250W ISOPLUS247 | IGBT 600V 75A 170W ISOPLUS247 | IGBT 600V 75A 250W ISOPLUS247 |
| Series | HiPerFAST™ | HiPerFAST™ | GenX3™ | HiPerFAST™ |
| Packaging | Tube | Tube | Tube | Tube |
