IXTR120P20T
Manufacturer
Littelfuse Inc.Description
MOSFET P-CH 200V 90A ISOPLUS247
Datasheet
DatasheetPackage
TO-247-3
In Stock
50,017 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IXTR120P20T
IXTR120P20T
lmages are for reference only.Payment Methods
Delivery Services
P-Channel 200 V 90A (Tc) 595W (Tc) Through Hole ISOPLUS247™
Quick Inquiry
IXTR120P20T
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Littelfuse Inc. |
| Series | TrenchP™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 200 V |
| Current - Continuous Drain (Id) @ 25°C | 90A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 32mOhm @ 60A, 10V |
| Vgs(th) (Max) @ Id | 4.5V @ 250µA |
| Vgs (Max) | ±15V |
| Input Capacitance (Ciss) (Max) @ Vds | 73000 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 595W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | ISOPLUS247™ |
| Package / Case | TO-247-3 |
| Base Product Number | IXTR120 |
| Gate Charge (Qg) (Max) @ Vgs | 740 nC @ 10 V |
| Grade | - |
| Qualification | - |
