Product CatalogPart Number
IXYN180N65A5
Manufacturer
IXYSDescription
650V, 180A, XP Gen5 A5 IGBT in S
Datasheet
DatasheetPackage
SOT-227-4, miniBLOC
In Stock
16,194 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IXYN180N65A5
IXYN180N65A5
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Single 650 V 340 A 940 W Chassis Mount SOT-227B
Quick Inquiry
IXYN180N65A5
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | IXYS |
| Series | Gen5 XPT™ |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Single |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector (Ic) (Max) | 340 A |
| Power - Max | 940 W |
| Vce(on) (Max) @ Vge, Ic | 1.35V @ 15V, 100A |
| Current - Collector Cutoff (Max) | 25 µA |
| Input Capacitance (Cies) @ Vce | 8640 pF @ 25 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | SOT-227-4, miniBLOC |
| Supplier Device Package | SOT-227B |
| Base Product Number | - |
