Product CatalogPart Number
JAH0224S09
Manufacturer
XP PowerDescription
DC DC CONVERTER 9V 2W
Datasheet
DatasheetPackage
24-DIP Module, 12 Leads
In Stock
59,250 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
JAH0224S09
JAH0224S09
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 9V 222mA 21.6V - 26.4V Input
Quick Inquiry
JAH0224S09
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | XP Power |
| Series | JAH (2W) |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 21.6V |
| Voltage - Input (Max) | 26.4V |
| Voltage - Output 1 | 9V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 222mA |
| Power (Watts) | 2 W |
| Applications | ITE (Commercial) |
| Features | SCP, UVLO |
| Operating Temperature | -40°C ~ 100°C |
| Efficiency | 63% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 24-DIP Module, 12 Leads |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | JAH0224 |
| Voltage - Isolation | 1 kV |
