JAN2N5683
Manufacturer
Microchip TechnologyDescription
TRANS NPN 60V 50A TO3
Datasheet
DatasheetPackage
TO-204AA, TO-3
In Stock
74,400 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
JAN2N5683
JAN2N5683
lmages are for reference only.Payment Methods
Delivery Services
Bipolar (BJT) Transistor NPN 60 V 50 A 300 W Through Hole TO-3 (TO-204AA)
Quick Inquiry
JAN2N5683
Specifications
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Transistor Type | NPN |
| Current - Collector (Ic) (Max) | 50 A |
| Voltage - Collector Emitter Breakdown (Max) | 60 V |
| Vce Saturation (Max) @ Ib, Ic | 5V @ 10A, 50A |
| Current - Collector Cutoff (Max) | 5µA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 15 @ 25A, 2V |
| Power - Max | 300 W |
| Frequency - Transition | - |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-204AA, TO-3 |
| Supplier Device Package | TO-3 (TO-204AA) |
| Base Product Number | 2N5683 |
| Grade | Military |
| Qualification | MIL-PRF-19500/466 |
