JANTX1N6150A/TR
lmages are for reference only.JANTX1N6150A/TR
TVS DIODE 16.7VWM 30.5VC C AXIAL
DatasheetG, Axial
20,669 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
30.5V Clamp 49.2A Ipp Tvs Diode Through Hole C, Axial
JANTX1N6150A/TR
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 16.7V |
| Voltage - Breakdown (Min) | 20.9V |
| Voltage - Clamping (Max) @ Ipp | 30.5V |
| Current - Peak Pulse (10/1000µs) | 49.2A |
| Power - Peak Pulse | 1500W (1.5kW) |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | G, Axial |
| Supplier Device Package | C, Axial |
| Base Product Number | - |
| Unidirectional Channels | - |
| Grade | Military |
| Qualification | MIL-PRF-19500/516 |
| Product Attribute | |
|
 |
|
| Part Number | JANTX1N6150A | JANTX1N6150AUS | JANTX1N6150AUS/TR | JANTX1N6100 |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | |
| Description | TVS DIODE 16.7VWM 30.5VC C AXIAL | TVS DIODE 16.7VWM 30.5VC SQ-MELF | BI-DIRECTIONAL TVS | TVS DIODE 14CFLATPACK |
| Series | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Packaging | Bulk | Bulk | Tape & Reel (TR) | Bulk |
