Product CatalogPart Number
JANTXV2N6798U
Manufacturer
Microsemi CorporationDescription
MOSFET N-CH 200V 5.5A 18ULCC
Datasheet
DatasheetPackage
18-CLCC
In Stock
95,064 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
JANTXV2N6798U
JANTXV2N6798U
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 200 V 5.5A (Tc) 800mW (Ta), 25W (Tc) Surface Mount 18-ULCC (9.14x7.49)
Quick Inquiry
JANTXV2N6798U
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 200 V |
| Current - Continuous Drain (Id) @ 25°C | 5.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 420mOhm @ 5.5A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | - |
| FET Feature | - |
| Power Dissipation (Max) | 800mW (Ta), 25W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 18-ULCC (9.14x7.49) |
| Package / Case | 18-CLCC |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 42.07 nC @ 10 V |
| Grade | Military |
| Qualification | MIL-PRF-19500/557 |
Parts with Similar Specifications
| Product Attribute |  |
|
|
|
| Part Number | JANTXV2N6798 | JANTXV2N6756 | JANTXV2N6760 | JANTXV2N6762 |
| Manufacturer | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation | Microsemi Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | MOSFET N-CH 200V 5.5A TO205AF | MOSFET N-CH 100V 14A TO204AA | MOSFET N-CH 400V 5.5A TO204AA | MOSFET N-CH 500V 4.5A TO204AA |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
