Product CatalogPart Number
JB15HFH
Manufacturer
NKK SwitchesDescription
SWITCH TACT SPST-NO 0.125A 24V
Datasheet
DatasheetPackage
-
In Stock
35,092 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
JB15HFH
JB15HFH
lmages are for reference only.Payment Methods
Delivery Services
Tactile Switch SPST-NO Top Actuated Through Hole, Right Angle
Quick Inquiry
JB15HFH
Specifications
| Category | Switches - Tactile Switches - |
| Manufacturer | NKK Switches |
| Series | JB |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Circuit | SPST-NO |
| Switch Function | Off-Mom |
| Contact Rating @ Voltage | 0.125A @ 24VDC |
| Actuator Type | Round Button |
| Mounting Type | Through Hole, Right Angle |
| Actuator Height off PCB, Vertical | - |
| Actuator Length, Right Angle | 1.46mm |
| Actuator Orientation | Top Actuated |
| Termination Style | PC Pin |
| Outline | 10.80mm x 6.54mm |
| Illumination | Non-Illuminated |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
| Operating Force | 265gf |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Features | Process Sealed |
| Operating Temperature | -25°C ~ 70°C |
| Actuator Material | Polybutylene Terephthalate (PBT) |
| Switch Travel | 0.30mm |
| Mechanical Life | 1,000,000 Cycles |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | JB15HFP | JB15FH | JB15FP | JB15FPG05 |
| Manufacturer | NKK Switches | NKK Switches | NKK Switches | NKK Switches |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SWITCH TACT SPST-NO 0.125A 24V | SWITCH TACTILE SPST-NO 0.05A 24V | SWITCH TACTILE SPST-NO 0.05A 24V | SWITCH TACTILE SPST-NO 0.4VA 28V |
| Series | JB | JB | JB | JB |
| Packaging | Tray | Tray | Tray | Bulk |
