JM54AC11SCA-RH
lmages are for reference only.JM54AC11SCA-RH
IC GATE AND 3CH 3-INP 14CERDIP
Datasheet14-CDIP (0.300", 7.62mm)
57,570 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
AND Gate IC 3 Channel 14-CERDIP
JM54AC11SCA-RH
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | National Semiconductor |
| Series | 54AC |
| Packaging | Bulk |
| RoHS Status | |
| Base Product Number | 54AC11 |
| Logic Type | AND Gate |
| Number of Circuits | 3 |
| Number of Inputs | 3 |
| Features | - |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Max) | 40 µA |
| Current - Output High, Low | 24mA, 24mA |
| Input Logic Level - Low | 0.9V ~ 1.65V |
| Input Logic Level - High | 2.1V ~ 3.85V |
| Max Propagation Delay @ V, Max CL | 8.5ns @ 5V, 50pF |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-CERDIP |
| Package / Case | 14-CDIP (0.300", 7.62mm) |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | JM54AC11S2A-RH | JM54AC11SDA-RH | JM54AC00BDA-RH | JM54AC00S2A-RH |
| Manufacturer | National Semiconductor | National Semiconductor | National Semiconductor | National Semiconductor |
| RoHS Status | ||||
| Description | IC GATE AND 3CH 3-INP 20LCCC | IC GATE AND 3CH 3-INP 14CFP | IC GATE NAND 4CH 2-INP 14CFP | IC GATE NAND 4CH 2-INP 20LCCC |
| Series | 54AC | 54AC | 54AC | 54AC |
| Packaging | Bulk | Bulk | Bulk | Bulk |
