JM54ACT00SCA-RH
lmages are for reference only.JM54ACT00SCA-RH
IC GATE NAND 4CH 2-INP 14CERDIP
Datasheet14-CDIP (0.300", 7.62mm)
68,046 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
NAND Gate IC 4 Channel 14-CERDIP
JM54ACT00SCA-RH
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | National Semiconductor |
| Series | 54ACT |
| Packaging | Bulk |
| RoHS Status | |
| Base Product Number | 54ACT00 |
| Logic Type | NAND Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | 40 µA |
| Current - Output High, Low | 24mA, 24mA |
| Input Logic Level - Low | 0.8V |
| Input Logic Level - High | 2V |
| Max Propagation Delay @ V, Max CL | 9.5ns @ 5V, 50pF |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-CERDIP |
| Package / Case | 14-CDIP (0.300", 7.62mm) |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | JM54ACT00BDA-RH | JM54ACT00S2A-RH | JM54ACT00SDA-RH | JM54AC00BDA-RH |
| Manufacturer | National Semiconductor | National Semiconductor | National Semiconductor | National Semiconductor |
| RoHS Status | ||||
| Description | IC GATE NAND 4CH 2-INP 14CFP | IC GATE NAND 4CH 2-INP 20LCCC | IC GATE NAND 4CH 2-INP 14CFP | IC GATE NAND 4CH 2-INP 14CFP |
| Series | 54ACT | 54ACT | 54ACT | 54AC |
| Packaging | Bulk | Bulk | Bulk | Bulk |
