Product CatalogPart Number
KAWS-2424TEL
Manufacturer
Diwell ElectronicsDescription
DC DC CONVERTER 24V 30W
Datasheet
DatasheetPackage
8-DIP Module, 6 Leads
In Stock
14,232 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
KAWS-2424TEL
KAWS-2424TEL
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 24V 1.25A 18V - 72V Input
Quick Inquiry
KAWS-2424TEL
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Diwell Electronics |
| Series | KAW-EL (30W) |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 18V |
| Voltage - Input (Max) | 72V |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1.25A |
| Power (Watts) | 30 W |
| Applications | ITE (Commercial) |
| Features | Adjustable Output, Remote On/Off |
| Operating Temperature | -40°C ~ 71°C |
| Efficiency | 80% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP Module, 6 Leads |
| Size / Dimension | 2.00" L x 2.00" W x 0.43" H (50.8mm x 50.8mm x 11.0mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | - |
| Voltage - Isolation | 1.5 kV |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | KAWS-2405TEL | KAWS-2409TEL | KAWS-2412TEL | KAWD-1205EL |
| Manufacturer | Diwell Electronics | Diwell Electronics | Diwell Electronics | Diwell Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER5V 30W | DC DC CONVERTER 9V 30W | DC DC CONVERTER 12V 30W | DC DC CONVERTER +/-5V 30W |
| Series | Diwell Electronics | Diwell Electronics | Diwell Electronics | Diwell Electronics |
| Packaging | Tube | Tube | Tube | Tube |
