Bipolar Motor Driver Bipolar Parallel, Serial 28-HDIP
LB11946-E
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | - |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (4) |
| Interface | Parallel, Serial |
| Technology | Bipolar |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 1A |
| Voltage - Supply | 3V ~ 3.6V, 4.5V ~ 5.5V |
| Voltage - Load | 10V ~ 45V |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 28-SDIP (0.500", 12.70mm) Exposed Pad |
| Supplier Device Package | 28-HDIP |
| Base Product Number | LB11946 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | LB11946-E | LB11948T-MPB-E | LB11948T-MPB-E | LB11948T-TLM-E |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ||||
| Description | IC MOTOR DRIVER BIPOLAR 28HDIP | IC MTR DRV BIPOLAR 3-15V 30TSSOP | IC MTR DRV BIPOLAR 3-15V 30TSSOP | IC MTR DRV BIPOLAR 3-15V 30TSSOP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
