LDA101STR
lmages are for reference only.LDA101STR
OPTOISO 3.75KV TRANS W/BASE 6SMD
Datasheet6-SMD, Gull Wing
32,074 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Transistor with Base Output 3750Vrms 1 Channel 6-SMD
LDA101STR
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | IXYS Integrated Circuits Division |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms |
| Current Transfer Ratio (Min) | 33% @ 1mA |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | 7µs, 20µs |
| Rise / Fall Time (Typ) | - |
| Input Type | DC |
| Output Type | Transistor with Base |
| Voltage - Output (Max) | 30V |
| Current - Output / Channel | - |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 1 mA |
| Vce Saturation (Max) | 500mV |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, Gull Wing |
| Supplier Device Package | 6-SMD |
| Base Product Number | LDA101 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LDA101 | LDA101S | LDA100 | LDA100S |
| Manufacturer | IXYS Integrated Circuits Division | IXYS Integrated Circuits Division | Littelfuse Inc. | Littelfuse Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISO 3.75KV TRANS W/BASE 6DIP | OPTOISO 3.75KV TRANS W/BASE 6SMD | OPTOISO 3.75KV TRANS W/BASE 6DIP | OPTOISO 3.75KV TRANS W/BASE 6SMD |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
