LF13509D
lmages are for reference only.LF13509D
IC SW SP4TX2 650OHM 16DIP
Datasheet16-DIP (0.300", 7.62mm)
14,678 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2 Circuit IC Switch 4:1 650Ohm 16-DIP
LF13509D
| Category | Integrated Circuits (ICs) - Interface - Analog Switches-Multiplexers-Demultiplexers |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Switch Circuit | SP4T - Open |
| Multiplexer/Demultiplexer Circuit | 4:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 650Ohm |
| Channel-to-Channel Matching (ΔRon) | - |
| Voltage - Supply, Single (V+) | - |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | - |
| -3db Bandwidth | - |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 2.2pF |
| Current - Leakage (IS(off)) (Max) | 20nA |
| Crosstalk | - |
| Operating Temperature | -40°C ~ 70°C |
| Mounting Type | Through Hole |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-DIP |
| Base Product Number | LF13509 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | LF13508D | LF13508D | LF13509D | LF11201D/883 |
| Manufacturer | National Semiconductor | National Semiconductor | National Semiconductor | National Semiconductor |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | SINGLE-ENDED MUX, 8 CH, BIPOLAR | SINGLE-ENDED MUX, 8 CH, BIPOLAR | IC SW SP4TX2 650OHM 16DIP | IC SW SPST-NCX4 200OHM 16CDIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Bulk |
