LFCG-2500+
lmages are for reference only.LFCG-2500+
LTCC LOW PASS FILTER, DC - 2500
Datasheet0805 (2012 Metric), 8 PC Pad
76,181 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.87GHz Low Pass Ceramic Filter 50Ohm 0805 (2012 Metric), 8 PC Pad
LFCG-2500+
| Category | Filters - Ceramic Filters - |
| Manufacturer | Mini-Circuits |
| Series | LFCG |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric), 8 PC Pad |
| Frequency | 2.87GHz |
| Impedance | 50Ohm |
| Bandwidth | - |
| Insertion Loss | 2.2dB |
| Filter Type | Low Pass |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Height (Max) | 0.037" (0.95mm) |
| Base Product Number | - |
| Product Attribute | |  | |  |
| Part Number | LFCG-2500+ | LFCG-1000+ | LFCG-1000+ | LFCG-1200+ |
| Manufacturer | Mini-Circuits | Mini-Circuits | Mini-Circuits | Mini-Circuits |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LTCC LOW PASS FILTER, DC - 2500 | LTCC LOW PASS FILTER, DC - 1000 | LTCC LOW PASS FILTER, DC - 1000 | LTCC LOW PASS FILTER, DC - 1200 |
| Series | LFCG | LFCG | LFCG | LFCG |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
