LFTCXO063710BULK
lmages are for reference only.LFTCXO063710BULK
XTAL OSC XO 12.0000MHZ HCMOS SMD
Datasheet8-SMD, No Lead
57,499 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
12 MHz TCXO HCMOS Oscillator 3.3V 8-SMD, No Lead
LFTCXO063710BULK
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | IQD Frequency Products |
| Series | IQXT-200-1-B |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | TCXO |
| Frequency | 12 MHz |
| Function | - |
| Output | HCMOS |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±280ppb |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -20°C ~ 70°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 10mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, No Lead |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) |
| Height - Seated (Max) | 0.094" (2.40mm) |
| Base Product Number | - |
| Product Attribute | |
 |
|
|
| Part Number | LFTCXO063709BULK | LFTCXO063711BULK | LFTCXO063712BULK | LFTCXO063713BULK |
| Manufacturer | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC TCXO 10.0000MHZ HCMOS | XTAL OSC TCXO 19.2000MHZ HCMOS | XTAL OSC TCXO 20.0000MHZ HCMOS | XTAL OSC TCXO 10.0000MHZ SNWV |
| Series | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| Packaging | Strip | Strip | Strip | Strip |
