LFTVXO009916BULK
lmages are for reference only.LFTVXO009916BULK
XTAL OSC VCTCXO 19.4400MHZ HCMOS
Datasheet8-SMD Module
82,910 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
19.44 MHz VCTCXO HCMOS Oscillator 3.3V 8-SMD Module
LFTVXO009916BULK
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | IQD Frequency Products |
| Series | CFPT-126 |
| Packaging | Strip |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | VCTCXO |
| Frequency | 19.44 MHz |
| Function | - |
| Output | HCMOS |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±500ppb |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 3mA (Typ) |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD Module |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) |
| Height - Seated (Max) | 0.079" (2.00mm) |
| Base Product Number | - |
| Product Attribute |  |
|
|
|
| Part Number | LFTVXO009900BULK | LFTVXO009901BULK | LFTVXO009905BULK | LFTVXO009907BULK |
| Manufacturer | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC VCTCXO 10.0000MHZ HCMOS | XTAL OSC VCTCXO 12.8000MHZ HCMOS | XTAL OSC VCTCXO 16.3840MHZ HCMOS | XTAL OSC VCTCXO 20.0000MHZ HCMOS |
| Series | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| Packaging | Bulk | Strip | Strip | Strip |
