LHL10NB151US
lmages are for reference only.LHL10NB151US
FIXED IND 150UH 950MA 290MOHM TH
DatasheetRadial, Vertical Cylinder
22,738 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
150 µH Unshielded Inductor 950 mA 290mOhm Max Radial, Vertical Cylinder
LHL10NB151US
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Taiyo Yuden |
| Series | LH, L Type |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | - |
| Material - Core | Ferrite |
| Inductance | 150 µH |
| Tolerance | - |
| Current Rating (Amps) | 950 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 290mOhm Max |
| Q @ Freq | 40 @ 796kHz |
| Frequency - Self Resonant | 2.9MHz |
| Ratings | - |
| Operating Temperature | -25°C ~ 105°C |
| Inductance Frequency - Test | 796 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.433" Dia (11.00mm) |
| Height - Seated (Max) | 0.551" (14.00mm) |
| Base Product Number | - |
| Product Attribute | |
|
 |
 |
| Part Number | LHL10NB150K | LHL10NB150K | LHL10NB151K | LHL10NB153J |
| Manufacturer | Taiyo Yuden | Taiyo Yuden | Taiyo Yuden | Taiyo Yuden |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 15UH 2.6A 42 MOHM TH | FIXED IND 15UH 2.6A 42 MOHM TH | FIXED IND 150UH 950MA 290MOHM TH | FIXED IND 15MH 90MA 34 OHM TH |
| Series | Taiyo Yuden | Taiyo Yuden | Taiyo Yuden | Taiyo Yuden |
| Packaging | Bulk | Bulk | Bulk | Bulk |
