LM2647LQX/NOPB
lmages are for reference only.LM2647LQX/NOPB
IC REG CTRLR BUCK 28WQFN
Datasheet28-WFQFN Exposed Pad
65,686 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Regulator Positive Output Step-Down DC-DC Controller IC 28-WQFN (5x5)
LM2647LQX/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 2 |
| Output Phases | 2 |
| Voltage - Supply (Vcc/Vdd) | 5.5V ~ 28V |
| Frequency - Switching | 200kHz ~ 500kHz |
| Duty Cycle (Max) | 75% |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Current Limit, Enable, Frequency Control, Power Good, Soft Start |
| Operating Temperature | -5°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 28-WFQFN Exposed Pad |
| Supplier Device Package | 28-WQFN (5x5) |
| Base Product Number | LM2647 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | LM2647LQ | LM2647LQ/NOPB | LM2647LQ/NOPB | LM2630MTCX-ADJ |
| Manufacturer | Texas Instruments | National Semiconductor | Texas Instruments | National Semiconductor |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant | |
| Description | IC REG CTRLR BUCK 28WQFN | LM2647 DUAL SYNCHRONOUS BUCK REG | IC REG CTRLR BUCK 28WQFN | SWITCHING CONTROLLER |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
