LM3152MHE-3.3
lmages are for reference only.LM3152MHE-3.3
SWITCHING CONTROLLER, 500KHZ
Datasheet14-PowerTSSOP (0.173", 4.40mm Width)
87,287 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Regulator Positive Output Step-Down DC-DC Controller IC 14-HTSSOP
LM3152MHE-3.3
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | National Semiconductor |
| Series | SIMPLE SWITCHER® |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 6V ~ 33V |
| Frequency - Switching | 500kHz |
| Duty Cycle (Max) | - |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Enable, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 14-PowerTSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-HTSSOP |
| Base Product Number | LM3152 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LM3152MH-3.3/NOPB | LM3152MHE-3.3/NOPB | LM3152MHX-3.3/NOPB | LM3000ASQ/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG CTRLR BUCK 14TSSOP | IC REG CTRLR BUCK 14TSSOP | IC REG CTRLR BUCK 14TSSOP | IC REG CTRLR BUCK 32WQFN |
| Series | SIMPLE SWITCHER® | SIMPLE SWITCHER® | SIMPLE SWITCHER® | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
