LM3302D
lmages are for reference only.LM3302D
IC COMPARATOR 4 GEN PUR 14SOIC
Datasheet14-SOIC (0.154", 3.90mm Width)
42,483 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Comparator General Purpose CMOS, MOS, Open-Collector, TTL 14-SOIC
LM3302D
| Category | Integrated Circuits (ICs) - Linear - Comparators |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | General Purpose |
| Number of Elements | 4 |
| Output Type | CMOS, MOS, Open-Collector, TTL |
| Voltage - Supply, Single/Dual (±) | 2V ~ 28V, ±1V ~ 14V |
| Voltage - Input Offset (Max) | 20mV @ 28V |
| Current - Input Bias (Max) | 0.5µA @ 5V |
| Current - Output (Typ) | 20mA |
| Current - Quiescent (Max) | 800µA |
| CMRR, PSRR (Typ) | - |
| Propagation Delay (Max) | - |
| Hysteresis | - |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Base Product Number | LM3302 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LM3302DR | LM3302DRG4 | LM3302M | LM3302M96 |
| Manufacturer | Texas Instruments | Texas Instruments | Harris Corporation | Intersil |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant |
| Description | IC COMPARATOR 4 GEN PUR 14SOIC | IC QUAD DIFF COMPARATOR 14-SOIC | IC COMPARATOR 4 GEN PUR 14SOIC | IC COMPARATOR 4 GEN PUR 14SOIC |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Bulk | Bulk |
