LM3409N/NOPB
lmages are for reference only.LM3409N/NOPB
IC LED DRIVER CTRLR PWM 14DIP
Datasheet14-DIP (0.300", 7.62mm)
17,606 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 1 Output DC DC Controller Step-Down (Buck) Analog, PWM Dimming 14-DIP
LM3409N/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Controller |
| Topology | Step-Down (Buck) |
| Internal Switch(s) | No |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 6V |
| Voltage - Supply (Max) | 42V |
| Voltage - Output | - |
| Current - Output / Channel | - |
| Frequency | - |
| Dimming | Analog, PWM |
| Applications | - |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Supplier Device Package | 14-DIP |
| Base Product Number | LM3409 |
| Grade | Automotive |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | LM3409N/NOPB | LM3409HVMY/NOPB | LM3409HVMYX/NOPB | LM3409MY/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRIVER CTRLR PWM 14DIP | IC LED DRIVER CTRLR PWM 10HVSSOP | IC LED DRIVER CTRLR PWM 10HVSSOP | IC LED DRIVER CTRLR PWM 10HVSSOP |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
