LM3686TLE-AADW/NOPB
lmages are for reference only.LM3686TLE-AADW/NOPB
LM3686 STEP-DOWN DC-DC CONVERTER
Datasheet12-WFBGA, DSBGA
93,434 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
PMIC - Voltage Regulators - Linear Switching 3 Output Step-Down (Buck) Synchronous (1), Linear (LDO) (2) 3MHz 12-DSBGA
LM3686TLE-AADW/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear Switching |
| Manufacturer | National Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Topology | Step-Down (Buck) Synchronous (1), Linear (LDO) (2) |
| Number of Outputs | 3 |
| Frequency - Switching | 3MHz |
| Voltage/Current - Output 1 | 1.8V, 600mA |
| Voltage/Current - Output 2 | 1.2V, 350mA |
| Voltage/Current - Output 3 | 2.8V, 300mA |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | No |
| Voltage - Supply | 2.7V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 12-WFBGA, DSBGA |
| Supplier Device Package | 12-DSBGA |
| Base Product Number | LM3686 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | LM3686TLE-AADW/NOPB | LM3686TLE-AAED/NOPB | LM3686TLE-AAED/NOPB | LM3686TLE-AAEF/NOPB |
| Manufacturer | Texas Instruments | National Semiconductor | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG TRPL BUCK/LNR SYNC 12USMD | SWITCHING REG, VOLTAGE-MODE, 1.3 | IC REG TRPL BCK/LNR SYNC 12DSBGA | IC REG TRPL BCK/LNR SYNC 12DSBGA |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
