LM3S101-IGZ20-C2
lmages are for reference only.LM3S101-IGZ20-C2
IC MCU 32BIT 8KB FLASH 48VQFN
Datasheet48-VFQFN Exposed Pad
26,478 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
ARM® Cortex®-M3 Stellaris® ARM® Cortex®-M3S 100 Microcontroller IC 32-Bit Single-Core 20MHz 8KB (8K x 8) FLASH 48-VQFN (7x7)
LM3S101-IGZ20-C2
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Texas Instruments |
| Series | Stellaris® ARM® Cortex®-M3S 100 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Core Processor | ARM® Cortex®-M3 |
| Core Size | 32-Bit Single-Core |
| Speed | 20MHz |
| Connectivity | Microwire, SPI, SSI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 18 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Data Converters | - |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 48-VQFN (7x7) |
| Package / Case | 48-VFQFN Exposed Pad |
| Base Product Number | LM3S101 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LM3S101-IGZ20-C2T | LM3S101-EGZ20-C2 | LM3S101-EGZ20-C2T | LM3S101-EQN20-C2 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 32BIT 8KB FLASH 48VQFN | IC MCU 32BIT 8KB FLASH 48VQFN | IC MCU 32BIT 8KB FLASH 48VQFN | IC MCU 32BIT 8KB FLASH 48LQFP |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tape & Reel (TR) | Tray | Tape & Reel (TR) | Tray |
