LMZ10503EXTTZ/NOPB
lmages are for reference only.LMZ10503EXTTZ/NOPB
DC DC CONVERTER 0.8-5V
DatasheetTO-PMOD-7, Power Module
80,410 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 5V 3A 2.95V - 5.5V Input
LMZ10503EXTTZ/NOPB
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Texas Instruments |
| Series | SIMPLE SWITCHER® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.95V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output 1 | 0.8 ~ 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 3A |
| Power (Watts) | - |
| Applications | ITE (Commercial) |
| Features | UVLO |
| Operating Temperature | -55°C ~ 125°C |
| Efficiency | 96% |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-PMOD-7, Power Module |
| Size / Dimension | 0.40" L x 0.39" W x 0.18" H (10.2mm x 9.9mm x 4.6mm) |
| Supplier Device Package | TO-PMOD-7 |
| Control Features | Enable, Active High |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | LMZ10503 |
| Voltage - Isolation | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LMZ10503EXTTZE/NOPB | LMZ10503EXTTZX/NOPB | LMZ10503TZ-ADJ/NOPB | LMZ10503TZE-ADJ/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DC DC CONVERTER 0.8-5V | DC DC CONVERTER 0.8-5V | DC DC CONVERTER 0.8-5V | DC DC CONVERTER 0.8-5V |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
