LO T67F-V1AB-24-1-20-R18-Z
lmages are for reference only.LO T67F-V1AB-24-1-20-R18-Z
LED ORANGE CLEAR 2PLCC SMD
Datasheet2-PLCC
74,007 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Orange 606nm LED Indication - Discrete 2.15V 2-PLCC
LO T67F-V1AB-24-1-20-R18-Z
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | ams-OSRAM USA INC. |
| Series | TOPLED® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Color | Orange |
| Configuration | Standard |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 1255mcd |
| Lens Style | Round with Flat Top |
| Lens Size | 2.40mm Dia |
| Voltage - Forward (Vf) (Typ) | 2.15V |
| Current - Test | 20mA |
| Viewing Angle | 120° |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 606nm |
| Wavelength - Peak | 610nm |
| Features | - |
| Package / Case | 2-PLCC |
| Supplier Device Package | 2-PLCC |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Height (Max) | 2.10mm |
| Base Product Number | LOT67F |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LO T67F-V1AA-23-1-20-R18-Z | LO T67F-V1AA-24-1-20-R18-Z-YA | LO T67F-V1AA-34-1-20-R18-Z | LO T67F-V1AA-34-1-20-R18-ZR-MM |
| Manufacturer | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED ORANGE CLEAR 2PLCC SMD | LED ORANGE CLEAR 2PLCC SMD | LED ORANGE CLEAR 2PLCC SMD | LED ORANGE CLEAR 2PLCC SMD |
| Series | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
