LP38500ASD-ADJ/NOPB
lmages are for reference only.LP38500ASD-ADJ/NOPB
IC REG LINEAR POS ADJ 1.5A 8WSON
Datasheet8-WFDFN Exposed Pad
70,117 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 1.5A 8-WSON (3x2.5)
LP38500ASD-ADJ/NOPB
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 0.6V |
| Voltage - Output (Max) | 5V |
| Voltage Dropout (Max) | 0.37 @ 1.5A |
| Current - Output | 1.5A |
| Current - Quiescent (Iq) | 15 µA |
| PSRR | 58dB ~ 56dB (120Hz ~ 1kHz) |
| Control Features | - |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-WFDFN Exposed Pad |
| Supplier Device Package | 8-WSON (3x2.5) |
| Base Product Number | LP38500 |
| Current - Supply (Max) | 3.5 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | LP38500ASDX-ADJ/NOPB | LP38500ATJ-ADJ/NOPB | LP38500SD-ADJ/NOPB | LP38500SDE-ADJ/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR POS ADJ 1.5A 8WSON | IC REG LIN POS ADJ 1.5A TO263 | IC REG LINEAR POS ADJ 1.5A 8WSON | IC REG LINEAR POS ADJ 1.5A 8WSON |
| Series | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
