LT3032MPDE-3.3#PBF
lmages are for reference only.LT3032MPDE-3.3#PBF
DUAL 200MA POSITIVE/NEGATIVE, LO
Datasheet14-PowerWFDFN
16,132 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive and Negative Fixed 2 Output 150mA, 150mA 14-DFN (4x3)
LT3032MPDE-3.3#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Configuration | Positive and Negative |
| Output Type | Fixed |
| Number of Regulators | 2 |
| Voltage - Input (Max) | ±20V |
| Voltage - Output (Min/Fixed) | ±3.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.27V @ 150mA (Typ), 0.3V @ 150mA (Typ) |
| Current - Output | 150mA, 150mA |
| Current - Quiescent (Iq) | - |
| PSRR | 68dB (120Hz), 54dB (120Hz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| Operating Temperature | -55°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 14-PowerWFDFN |
| Supplier Device Package | 14-DFN (4x3) |
| Base Product Number | - |
| Current - Supply (Max) | - |
| Product Attribute | |
 |
 |
 |
| Part Number | LT3032MPDE-3.3#PBF | LT3032MPDE-3.3#TRPBF | LT3032MPDE#PBF | LT3032MPDE#TRPBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR +-3.3V 14DFN | IC REG LINEAR +-3.3V 14DFN | IC REG LINEAR POS/NEG ADJ 14DFN | IC REG LINEAR POS/NEG ADJ 14DFN |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
