LT3089IFE#PBF
lmages are for reference only.LT3089IFE#PBF
LT3089 - 800MA SINGLE RESISTOR R
Datasheet16-TSSOP (0.173", 4.40mm Width) Exposed Pad
90,295 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 800mA 16-TSSOP-EP
LT3089IFE#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 36V |
| Voltage - Output (Min/Fixed) | 0V |
| Voltage - Output (Max) | 34.5V |
| Voltage Dropout (Max) | 1.65V @ 800mA |
| Current - Output | 800mA |
| Current - Quiescent (Iq) | 50.5 µA |
| PSRR | 90dB ~ 20dB (120Hz ~ 1MHz) |
| Control Features | Current Limit |
| Protection Features | Over Current, Over Temperature, Reverse Polarity, Short Circuit |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 16-TSSOP-EP |
| Base Product Number | - |
| Current - Supply (Max) | 51.25 µA |
| Product Attribute |  |
 |
 |
 |
| Part Number | LT3089IFE#PBF | LT3089IFE#TRPBF | LT3089IDF#PBF | LT3089IDF#TRPBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LIN POS ADJ 800MA 16TSSOP | IC REG LIN POS ADJ 800MA 16TSSOP | IC REG LIN POS ADJ 800MA 12DFN | IC REG LIN POS ADJ 800MA 12DFN |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tape & Reel (TR) |
