LT3596EUHG#PBF
lmages are for reference only.LT3596EUHG#PBF
IC LED DRV RGLTR PWM 100MA 52QFN
Datasheet52-WFQFN, 39 Leads, Exposed Pad
76,844 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 3 Output DC DC Regulator Step-Down (Buck) PWM Dimming 100mA 52-QFN (5x8)
LT3596EUHG#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Down (Buck) |
| Internal Switch(s) | Yes |
| Number of Outputs | 3 |
| Voltage - Supply (Min) | 6V |
| Voltage - Supply (Max) | 55V |
| Voltage - Output | - |
| Current - Output / Channel | 100mA |
| Frequency | 200kHz ~ 1MHz |
| Dimming | PWM |
| Applications | Backlight, Signage |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 52-WFQFN, 39 Leads, Exposed Pad |
| Supplier Device Package | 52-QFN (5x8) |
| Base Product Number | LT3596 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LT3596EUHG#TRPBF | LT3517EFE#PBF | LT3517EFE#TRPBF | LT3517EUF#PBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRV RGLTR PWM 100MA 52QFN | IC LED DRV RGLTR PWM 16TSSOP | IC LED DRV RGLTR PWM 16TSSOP | IC LED DRVR RGLTR PWM 1.5A 16QFN |
| Series | - | True Color PWM™ | True Color PWM™ | True Color PWM™ |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR) | Tube |
