LTC3119MPFE#TRPBF
lmages are for reference only.LTC3119MPFE#TRPBF
IC REG BUCK BOOST ADJ 5A 28TSSOP
Datasheet28-TSSOP (0.173", 4.40mm Width) Exposed Pad
13,736 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck-Boost Switching Regulator IC Positive Adjustable 0.8V 1 Output 5A 28-TSSOP (0.173", 4.40mm Width) Exposed Pad
LTC3119MPFE#TRPBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Buck-Boost |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.5V |
| Voltage - Input (Max) | 18V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Voltage - Output (Max) | 18V |
| Current - Output | 5A |
| Frequency - Switching | 400kHz ~ 2MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -55°C ~ 150°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 28-TSSOP-EP |
| Base Product Number | LTC3119 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LTC3119MPFE#PBF | LTC3119EFE#PBF | LTC3119EFE#TRPBF | LTC3119EUFD#PBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG BUCK BOOST ADJ 5A 28TSSOP | IC REG BUCK BOOST ADJ 5A 28TSSOP | IC REG BUCK BOOST ADJ 5A 28TSSOP | IC REG BUCK BOOST ADJ 5A 28QFN |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tube |
