Buck Regulator Positive Output Step-Down DC-DC Controller IC 10-DFN (3x3)
LTC3822EDD#PBF
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 2.75V ~ 4.5V |
| Frequency - Switching | 300kHz, 550kHz, 750kHz |
| Duty Cycle (Max) | 99% |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Enable, Frequency Control |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 10-WFDFN Exposed Pad |
| Supplier Device Package | 10-DFN (3x3) |
| Base Product Number | LTC3822 |
| Grade | - |
| Qualification | - |
| Product Attribute | | |  | |
| Part Number | LTC3822EDD#PBF | LTC3822EDD#TRPBF | LTC3822EDD-1 | LTC3822EDD-1#PBF |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC REG CTRLR BUCK 10DFN | IC REG CTRLR BUCK 10DFN | IC POWER MANAGEMENT | IC REG CTRLR BUCK 12DFN |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tube |
