LTS-3361JD
lmages are for reference only.LTS-3361JD
DISPLAY 7-SEG 0.3" SGL RED 10DIP
Datasheet10-DIP (0.200", 5.08mm)
56,196 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Display Modules - LED Character and Numeric Red 7-Segment 1 Character Common Cathode 2.1V 20mA 0.500" H x 0.300" W x 0.240" D (12.70mm x 7.62mm x 6.09mm) 10-DIP (0.200", 5.08mm)
LTS-3361JD
| Category | Optoelectronics - LED Character and Numeric - |
| Manufacturer | Lite-On Inc. |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Number of Characters | 1 |
| Size / Dimension | 0.500" H x 0.300" W x 0.240" D (12.70mm x 7.62mm x 6.09mm) |
| Digit/Alpha Size | 0.30" (7.62mm) |
| Display Type | 7-Segment |
| Common Pin | Common Cathode |
| Color | Red |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Current - Test | 20mA |
| Millicandela Rating | 0.6mcd |
| Wavelength - Peak | 650nm |
| Power Dissipation (Max) | 70mW |
| Package / Case | 10-DIP (0.200", 5.08mm) |
| Base Product Number | LTS-3361 |
| Display Format | - |
| Product Attribute | |
|
|
|
| Part Number | LTS-3361JG-06 | LTS-3361JR | LTS-10304G | LTS-10804E |
| Manufacturer | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | N/D LTS-3361JG-06 S/D DISPLAY | DISPLAY 7-SEG 0.3" SGL RED 10DIP | DISPLAY 7-SEG 1" SGL GREEN 14DIP | DISP 7SEG 1" SGL ORG-RED 14DIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
