LTST-S115KGKFKT-5A
lmages are for reference only.LTST-S115KGKFKT-5A
LED GREEN/ORANGE CLEAR 2SMD R/A
Datasheet2-SMD, No Lead
66,300 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Green, Orange 572nm Green, 607nm Orange LED Indication - Discrete 2.05V Green, 2.05V Orange 2-SMD, No Lead
LTST-S115KGKFKT-5A
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Lite-On Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Color | Green, Orange |
| Configuration | Common Anode |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 16mcd Green, 20mcd Orange |
| Lens Style | Rectangle with Domed Top |
| Lens Size | 2.00mm x 1.00mm |
| Voltage - Forward (Vf) (Typ) | 2.05V Green, 2.05V Orange |
| Current - Test | 5mA Green, 5mA Orange |
| Viewing Angle | 120° |
| Mounting Type | Surface Mount, Right Angle |
| Wavelength - Dominant | 572nm Green, 607nm Orange |
| Wavelength - Peak | 575nm Green, 611nm Orange |
| Features | - |
| Package / Case | 2-SMD, No Lead |
| Supplier Device Package | 2-SMD |
| Size / Dimension | 3.20mm L x 1.50mm W |
| Height (Max) | 1.00mm |
| Base Product Number | LTST-S115 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LTST-S110KFKT | LTST-S110KGKT | LTST-S110KRKT | LTST-S110KSKT |
| Manufacturer | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED ORANGE CLEAR SMD R/A | LED GREEN CLEAR SMD R/A | LED RED CLEAR SMD R/A | LED YELLOW CLEAR CHIP SMD |
| Series | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. | Lite-On Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
