LV5747NTT-TLM-E
lmages are for reference only.Payment Methods
Delivery Services
Buck Regulator Positive Output Step-Down DC-DC Controller IC 12-MSOP
LV5747NTT-TLM-E
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Sanyo |
| Series | - |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 8V ~ 42V |
| Frequency - Switching | 300kHz |
| Duty Cycle (Max) | 92% |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Current Limit, Enable, Soft Start |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 12-TFSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 12-MSOP |
| Base Product Number | LV5747 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
|
| Part Number | LV5747NTT-TLM-E | LV5747NTTL-TLM-E | LV5747NTTL-TLM-E-SY | LV5743V-TLM-E |
| Manufacturer | onsemi | onsemi | Sanyo | onsemi |
| RoHS Status | Not applicable | Not applicable | ||
| Description | IC REG CTRLR BUCK 12MSOP | STEP-DOWN SWITCHING REGULATOR | STEP-DOWN SWITCHING REGULATOR | IC REG CTRLR BUCK PWM 42V |
| Series | - | * | * | * |
| Packaging | Tape & Reel (TR) | Bulk | Bulk | Tape & Reel (TR) |
